M950 - Ultra High Capacity truss with free-span up to 40m

The largest aluminium truss series from MILOS with maximum loading and free-span specifications for your temporary or permanent installations.
Select format:
FoldRect
Code
FTT
Main Tube
60x6mm
Braces
32x3mm
Available Length
1 - 3 m
Max. SWL
4774 kg
Size
580 x 1000 mm
Span
40 m

Download PDF

Basic info

Description

If you require maximum loading specifications and free-span characteristics for your temporary or permanent installations, look no further than the Milos M950 truss system. M950 is the newest and largest Milos truss system.
Call or e-mail us today for more information or to receive a quote.

Key benefits

  • Newly heavy duty RTTH available with up to 50% better SWL
  • User friendly taper pin hole orientation for ease of assembly
  • Ultra-high capacity M950 series truss range
  • Fixed rectangular or compact folding version available
  • Great free-span & loading characteristics (upto 40m / 131.23 ft)
  • Connection kit supplied with every truss length
  • Super-size connical connection for maximum rigidity
  • Cell clamp 300 series compatible
  • Transit wheels fitted for ease of transportation & setup
  • Powder coat colour finish available on request

Tables



M950 - Standard lengths and weights available
  1 m 1.2 m 2 m 2.4 m 3 m
Fold 24 kg 27.5 kg 43.9 kg 48.5 kg 62.6 kg
Rect 30 kg 33.6 kg 51 kg 56 kg 71 kg
